TK01H201 - Stage 1 Organic, Single Series - EXEDY

Manufacturer: Exedy

SKU: TK01H201

Be the first to review this product

192.22 EUR

Incl. 0% VAT (United States) | Change

192.22 EUR excl. VAT

TK01H201 - Stage 1 Organic, Single Series - EXEDY

Availability: Out of stock - If ordered, it will be shipped once available (3-7 days).

Qty:

+ -

Specs

SERIES	Single Series	CLUTCH TYPE	Stage 1 Organic
CLAMP LOAD (N)	5400	FRICTION FACING	Organic
DISC DIAMETER (mm)	200	SPRUNG CENTRE	Yes
MAX TORQUE @ FLYWHEEL	150 lb.ft./200 Nm	MAX TORQUE @ WHEELS	120 lb.ft./160 Nm
NUMBER OF PADDLES		PUSH / PULL BEARING	Push
SUPPLEMENTARY ARTICLE INFO	With bearing(s)

*if the vehicle is unmodified, a performance clutch is not recommended

FITMENT

MAKE	MODEL	MODEL CODE	LITRE	YEAR
TOYOTA	COROLLA	AE86	1.6	1983-1987

Precision, strength and incomparable quality.

Designed for lightly modified vehicles, the Stage 1 Organic clutch incorporates friction material with high heat-resistance properties and high strength fibres making it an ideal clutch for road, circuit or drifting.

Main Benefits

Ensures the clutch engagement feeling is the same as the standard clutch.
Up to a 30% increase in torque capacity over standard.
Approximately 40% higher clamp load than the standard clutch.
Industry-leading performance friction, achieving the highest fade recovery, the highest RPM burst test results, the best heat resistance and the lowest wear rate in the performance aftermarket.

Clutch Cover

Single Series clutch covers are designed to achieve a clamping load that is approximately 40% higher than the genuine part enabling a higher torque capacity. Ductile material is used for all pressure plates and high burst strength can be achieved in all temperature ranges.

Note: Single Series Clutch Kits with HD in the middle of a kit reference denote that the cover has a higher clamp load. e.g. Mitsubishi EVO Organic kit: MK04HD601

Clutch Disc

An ultra fibre friction facing is used which has high heat resistance and high burst strength characteristics. No steel back is required which can cause RPM "lock-out" and/or synchro damage. Superior in shift operations and half-engagement feel, this clutch disc is recommended for any motorsport or modified vehicle use.

The performance of a standard organic friction material usually suffers after slipping. Accordingly, EXEDY has developed the ultra fibre material. If fade is experienced it will recover after a short cooling down period.

Note: There are two variations of Organic kits for some models. For example, the Organic kit FK01H601 for the Subaru Impreza has a 6 spring disc and the kit FK01H1601 has a 4 spring disc. The 6 spring disc is best suited for track day or motorsport use, whereas the 4 spring disc is ideal for everyday driving as it delivers a smooth engagement and disengagement experience.

Clutch Type

Friction Facing

Disc Diameter

Disc Damper

Rattle Noise When Disengaged

Typical Usage

Engine Torque

Acceleration Response

Shift Response Speed

Engagement Feeling

Pedal Effort
[Weight]

Advantages

10 = High
5 = Genuine
1 = Low

10 = Good
5 = Genuine
1 = Dull

10 = Good
5 = Genuine
1 = Bad

10 = Genuine
1 = Difficult

10 = Genuine
1 = Heavy

Stage 1 Organic

Single Plate

Organic

Same as Genuine

Yes

Vehicle Type: All Types
Usage: Street / Track Day

- Ensures the clutch engagement feeling is the same as the standard clutch.
- The organic friction facing maintains heat resistance whilst allowing up to a 30% increase in torque capacity over standard.
- Approximately 40% higher clamp load than the standard clutch.

SINGLE SERIES

Stage 2 Sports

Single Plate

Cerametallic

Same as Genuine

Yes

Vehicle Type: All Types
Usage: Circuit / Drift / Drag / Rally.

- A reduction of 10% inertia over the original equipment part increases the shift feeling.
- The cerametallic friction facing maintains heat resistance whilst allowing up to a 40% increase in torque capacity over standard.
- Approximately 40% higher clamp load than the standard clutch.

Stage 2 Racing

Single Plate

Cerametallic

Same as Genuine

Yes

Vehicle Type: Lightly modified circuit Vehicle Type (e.g. Civic).
Usage: Track day / Competition Racing.

- A reduction of 30% inertia over the original equipment part increases the shift feeling.
- The cerametallic friction facing maintains heat resistance whilst allowing up to a 40% increase in torque capacity over standard.
- Approximately 40% higher clamp load than the standard clutch.

Stage 2 Rally

Single Plate

Cerametallic

Same as Genuine

Yes

Vehicle Type: Rally Vehicle Type with high torque capacity.
Usage: Group N Rally.

- Specifically designed for Group N Rally.
- Can handle up to 630Nm at the flywheel.
- Approximately 40% higher clamp load than the standard clutch.

HYPER SERIES

Hyper Single

Single Plate

Cerametallic

200mm / 225mm

Yes

Vehicle Type: Modofied NA / Turbo engine.
(e.g. Civic / S2000 / Silvia / Impreza)
Usage: Circuit / Drift / Drag

- Quick acceleration response due to low inertia created from the lightweight design.

Hyper Single VF (Various Friction)

Single Plate

Cerametallic / Organic

200mm / 225mm

Yes

Vehicle Type: Modified NA / Turbo engine.
(e.g. Civic / S2000 / Silvia / Impreza)
Usage: Street & Track Day

- Capable of handling a high torque capacity without sacrificing the feel of a standard clutch.
- Combination of cerametallic & organic friction facings allows for high heat durability.
- Unique cushioning plate design reduces pedaling power by 12%.

Hyper Multi Twin

Twin Plate

Cerametallic

200mm

Yes

Vehicle Type: Highly tuned performance engines.

(e.g. Supra / EVO / Impreza / Skyline).
Usage: Street / Circuit / Drift / Drag.

- High torque capacity.
- Self leveling intermediate plate design reduces gearbox rattle and increases the disengagement performance (PAT.).
- Unique intermediate plate design increases heat resistance which improves clutch life.

Hyper Multi Triple

Triple Plate

Cerametallic

200mm

Yes

Vehicle Type: Heavily tuned performance engines
(e.g. Supra / EVO / Impreza / Skyline).
Usage: Drag Racing / Drifting.

- Capable of handling the highest torque capacities associated with motorsports.

Compe - R

Cerametallic

200mm

Yes

Vehicle Type: Competition Vehicle Types
(e.g. EVO / Impreza / RX7)
Usage: Circuit.

- Lightweight flywheel allows for quicker acceleration response due to lower inertia.
- High Torque Capacity.

Compe - D

Cerametallic

200mm

Yes

Vehicle Type: Competition Vehicle Types
(e.g. EVO / Impreza / RX7)
Usage: Drift / circuit / Gymkhana.

- Lightweight flywheel allows for quicker acceleration response due to lower inertia.
- Absorbs additional gearbox rattle and shock torque compared to Compe-R.

Carbon - D

Single Plate

Carbon

202mm / 225mm

Yes

Vehicle Type: High-performance NA engine
(e.g. s2000 / Integra / RX8).
Usage: Street / Circuit.

- Carbon clutches offer excellent operational feel by reducing inertia.
- Unique damper design significantly reduces shock torque and gearbox rattle.
- The highest possible performance with the same ease of use as the original equipment clutch.
- Added SX coating to the pressure plate and intermediate plate further increases stability and torque capacity.

Carbon - D

Twin Plate

Carbon

225mm

Yes

Vehicle Type: High-performance turbo engine
(e.g. EVO / Impreza / Skyline / Supra)
Usage: Street / Circuit

Carbon - R

Single Plate

Carbon

202mm / 225mm

Vehicle Type: High-performance NA engine
(e.g. s2000 / Integra / RX8).
Usage: Street / Circuit.

- Rigid type center hub design gives the Carbon-R the ultimate shift response.
- Lightweight flywheel and hub design significantly reduces inertia, giving excellent acceleration response.
- Added SX coating to the Pressure plate and Intermediate plate further increases stability and torque capacity.

Carbon - R

Twin Plate

Carbon

202mm

Yes

Vehicle Type: High-performance turbo engine
(e.g. EVO / Impreza / Skyline / Supra)
Usage: Street / Circuit

Carbon - R

Triple Plate

Carbon

202mm

Yes

Vehicle Type: High-performance turbo engine
(e.g. EVO / Impreza / Skyline / Supra)
Usage: Street / Circuit

Products specifications

Gearbox	Toyota C52
Product Type	Exedy
Model	Corolla
Year	1984–1987 (AE86)
Make	Toyota
Disc Facing / Material	Organic
Centre Disc	Sprung
Power Rating @ Flywheel /Nm	200 Nm
Engine	Toyota 4A-GEU
