GT86/BRZ Heavy Duty Sprung Ceramic Incl Flywheel 540Nm, Clutch Kit - Xtreme Performance

Manufacturer: Xtreme Clutch

SKU: KSU23512-1B

Be the first to review this product

903.76 EUR

Incl. 0% VAT (United States) | Change

903.76 EUR excl. VAT

Heavy Duty Sprung Ceramic Incl Flywheel 540Nm, Clutch Kit

Xtreme Performance - sprung ceramic kit /-1B
Recommended for: Motorsport Applications

Availability: Out of stock - If ordered, it will be shipped once available (3-7 days).

Qty:

+ -

Overview
Specifications
CBS Racing Warranty
Reviews
Contact Us

Heavy Duty Sprung Ceramic Incl Flywheel 540Nm, Clutch Kit

Xtreme Performance - sprung ceramic kit /-1B
Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

Specifications:

Torque capacity 540Nm
Clamp load Increased over standard
Sprung Ceramic Friction Disc
Heavy Duty Pressure Plate
Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits has been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilize a sprung hub that helps to reduce shock loading and is commonly used in track cars that retain the factory transmission.

Clutch Disc Diameter (mm): 230
Clutch Disc Spline Count: 24
Clutch Disc Spline Diameter (mm): 25.2
Torque (Nm): 540
Flywheel: Step-2
Design: Single Plate
Stage: Stage 2
Recommended for: Track - Stage 2
Weight [KG]: 14.46

Make	Model	Year	Variant	Engine
SUBARU	BRZ	2012.06-	2.0 (ZC6)	FA20D, FA20C 1998 Petrol 147 kW 200 BHP (2012.06 -)
TOYOTA	GT 86 coupe	2012.03-	2.0 (ZN6AC_. ZN6BC_)	FA20, FA20D, 4U-GSE 1998 Petrol 147 kW 200 BHP (2012.03 -)
TOYOTA	GT 86 coupe	2016.08-	2.0 (ZN6EY_)	FA20D, 4U-GSE 1998 Petrol 152 kW 207 BHP (2016.08 -)

Xtreme Performance

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs

What's in the Box?
Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Products specifications

Engine	Subaru FA20, Subaru FA20D
Product Type	Clutch Kits
Make	Toyota, Subaru
Model	BRZ, GT86
Clutch Disc Diameter (mm)	230mm
Power Rating @ Flywheel /Nm	540 Nm
Disc Facing / Material	Ceramic
Disc Quantity	Single Disc
Centre Disc	Sprung
