6An Dry Break 27Mm Set - Radium – Discontinued

** DISCONTINUED **

Please note, the chosen part is discontinued and therefore most likely not available for purchase!
(You won't be able to add it to your cart)

However, if this item is still in stock at CBS Racing, you will be able to buy it!

• If you see the "ADD TO CART" button we may have this item in stock, please try to add it to your cart.
• If you can not add it to your cart, we no longer have any left and we will remove the "ADD TO CART" button shortly.

Note: If the part you are looking for is discontinued, don't hesitate to contact us! There might be a replacement part available or we may be able to find a Used or Second-Hand part for you.
-----------------------------------------------------------

Simply push and twist the knurled machined surface. They are designed for use in fuel or oil applications and are available in -6AN and/or -8AN flare fittings. The couplers have been successfully tested on Radium's test bench at 150psi engaged and disengaged.

The anodized aluminum fittings are available as a set (inner and outer) or as individual parts.

If a step up (or down) in hose size is required, the -8AN and -6AN fittings are interchangeable and can be configured as shown below.

Important Notes:
-Not compatible with methanol fuel.
-These fittings flow equally in both directions and can be installed either way.
-The higher the operating pressure, the more difficult it becomes to connect and disconnect the coupler.
-Due to the dry break coupler design, there will be some inherent flow restriction (pressure drop).
-Naturally there might be a drop when engaging and disengaging.
-Do not disconnect fittings while pumps are running.

Technical Data:
-Overall length: -6AN kit = 82mm, -8AN kit = 87mm
-Weight: -6AN kit = 62g, -8AN kit = 69g
-Average pressure drop across coupler: 1-2psi
-Flow loss: 2% at 800LPH
